Asphalt Tanker Trailer
Engineered with precision, our asphalt tanker trailers ensure the safe and efficient transport of liquid asphalt and bitumen. By combining high-grade materials with advanced thermal insulation, these trailers effectively maintain stable temperatures even during long hauls. In addition, their rugged construction guarantees durability across a variety of challenging road conditions. Furthermore, optional heating systems and multiple capacity options add versatility, providing flexibility to meet different transport needs.
As a trusted OEM supplier, Shandong ZW Vehicle Group brings over 10 years of export experience to every partnership. Moreover, we operate a 50,000m² production facility and proudly serve customers in more than 60 countries worldwide, demonstrating our strong global presence and commitment to quality.
Ready to Order? Get Your Quote Today!
Expert support worldwide — get your personalized quote today.
📌 Product Overview
Why Choose ZW Group Asphalt Tanker Trailer?
With over 10 years of experience producing and exporting asphalt tanker trailers and related equipment, Shandong ZW Vehicle Group has built a strong global reputation. Trusted by clients in more than 60 countries, we consistently deliver reliable products, customized transport solutions, and responsive after-sales service. Furthermore, our 50,000m² facility houses advanced CNC and welding machinery, operated by over 200 skilled workers who are dedicated to manufacturing safe and efficient bitumen transport trailers.
Each asphalt tanker trailer is engineered to provide excellent heat retention, smooth discharge, and strong adaptability to diverse climates and road conditions. In addition, strict quality control is maintained throughout production to ensure dependable delivery worldwide. Therefore, whether supporting road construction projects or managing long-distance asphalt transport, customers can always count on ZW Group’s durable and proven tanker trailers.
Applications in Logistics & Industry
Asphalt tanker trailers play a vital role in road construction, infrastructure maintenance, and bitumen logistics. Specifically designed for the safe and efficient transport of hot liquid asphalt, these specialized trailers are indispensable in large-scale paving and surfacing projects. In addition, timely delivery of heated bitumen is critical in the construction industry because it allows contractors to maintain proper material temperatures and meet tight project deadlines.
Thanks to advanced insulation and integrated heating systems, these tankers effectively minimize heat loss during transport. As a result, operational efficiency is enhanced while material waste is significantly reduced. Moreover, asphalt tankers are widely used by asphalt plants, government contractors, and logistics providers who require dependable solutions for long-distance or regional transport. With their high load capacity and excellent thermal performance, these trailers have become essential equipment in modern road-building operations.
🛠️ Operation & Specifications
How to Load Asphalt into an Asphalt Tanker Trailer？
Loading asphalt into an asphalt tanker trailer requires careful handling to ensure both operational efficiency and safety. To begin with, the trailer should be positioned on a level surface near the asphalt mixing station. This stable setup helps prevent spills or tipping during loading. After that, operators connect the trailer’s inlet to the asphalt discharge pipe using high-temperature-resistant hoses.
Once the connection is securely in place, the pump can be activated, or alternatively, gravity-fed loading may be employed depending on the system design. Throughout the process, it is crucial to monitor temperature and flow rate carefully in order to avoid overheating or overfilling. When the tank reaches the desired level, operators must ensure all valves are tightly closed before disconnecting the hoses.
Finally, conducting a thorough inspection of the pressure system and safety vents is necessary to confirm that the trailer is ready for transport. By following these steps diligently, operators can guarantee a safe and efficient loading process while maintaining ideal transport conditions.
Basic Specifications Table
4-Axle Asphalt Tanker Trailer Technical Drawing
| Item | Specification |
|---|---|
| Overall Dimensions | 15000 × 2550 × 4270 mm |
| Tank Volume | 80CBM |
| Compartments | 4 Compartments |
| Tank Material | 6mm Q235B Carbon Steel |
| End Plate | 6mm Q235 Carbon Steel |
| Axles | 4 × 16 Ton (BPW / FUWA Optional) |
| Suspension | Mechanical Suspension |
| Landing Gear | JOST D200T |
| Kingpin | JOST 2″ or 3.5″ Bolt-in |
| Tires | 12.00R22.5 |
Single-Compartment Oil Tanker Semi-Trailer with 3 Axles – Blueprint
Oil Tanker Blueprint Version 2: Single Compartment, 3 Axles
Three-Compartment Oil Tanker Design for 3-Axle Semi-Trailer
📦 Delivery & Components
Package & Shipping Methods
At Shandong ZW Vehicle Group, we take great care to securely package and prepare every asphalt tanker trailer for safe international transport. Before shipping, each unit undergoes thorough inspection, partial assembly, and careful fastening to minimize damage risks during transit. Depending on customer preferences and destination port facilities, shipments are arranged via container or Ro-Ro (Roll-on/Roll-off) vessels.
In addition, our experienced logistics team collaborates closely with reliable freight partners to ensure timely and secure delivery worldwide. To better support clients, customized shipping solutions are offered, including inland transportation, port handling, and customs clearance assistance. As a result, customers enjoy a smooth, hassle-free purchasing experience from factory to final destination.
Key Parts Overview
The asphalt tanker trailer includes key components designed not only for durability, safety, but also for efficient transport of hot asphalt, making it an ideal choice for road construction, paving projects, and industrial asphalt delivery:
Insulated Tank: Constructed from high-quality carbon steel with advanced thermal insulation, the tank effectively maintains optimal asphalt temperature during transit and significantly minimizes heat loss, thereby ensuring material quality throughout the journey.
Chassis Frame: Built with a heavy-duty steel frame chassis, it provides robust structural support, impressive load-bearing capacity, and enhanced stability under heavy and uneven loads. Consequently, the trailer can withstand harsh working conditions.
Axles and Suspension: Equipped with a multi-axle air suspension system, the trailer delivers smooth ride handling, improved weight distribution, and better off-road performance, which makes it suitable for various terrain conditions.
Heating System: An integrated diesel burner heating unit works in conjunction with the insulation to keep asphalt at the required temperature, thus ensuring material fluidity and preventing solidification during long-distance transport.
Loading and Discharge Equipment: Features secure, leak-proof top-loading hatches and efficient discharge valves to facilitate safe, fast, and spill-free asphalt loading and unloading operations.
Braking System: A reliable air brake system with responsive controls enhances road safety, provides precise stopping power, and complies fully with transportation regulations.
Lighting: Moreover, high-visibility LED tail lights, side markers, and safety reflectors improve visibility in low-light and nighttime conditions while adhering to road safety standards.
Toolbox and Accessories: For added convenience, integrated tool compartments, safety equipment, and essential maintenance accessories support daily operations, emergency repairs, and onsite service needs.
Thanks to this comprehensive design, the asphalt tanker trailer stands out as a dependable, high-performance hauling solution for transporting hot asphalt across various construction sites, infrastructure projects, and industrial applications.
🔧 Design Advantages
Main Beam Features
The main beam acts as the critical structural backbone of the asphalt tanker trailer, engineered not only for maximum strength and durability but also for efficient load distribution. Its key characteristics include:
Premium Steel Fabrication: Constructed from high-quality Q345 steel, the beam effectively resists bending and deformation, even under heavy payloads and rough road conditions.
Optimized Structural Thickness: Featuring a well-balanced design—with an upper plate about 14mm thick, a lower flange near 16mm, and an 8mm web plate—this structure successfully combines strength with weight efficiency.
Enhanced Corrosion Protection: Furthermore, the surface is coated with advanced anti-corrosion materials, thereby ensuring long-lasting durability against asphalt residue, weather, and harsh environments.
Precision Welding Technology: Thanks to cutting-edge welding methods, strength is evenly distributed across joints, which reduces stress concentration and consequently boosts reliability.
Seamless Suspension Integration: In addition, the beam is designed to work smoothly with multi-axle air suspension systems, improving ride comfort and stabilizing cargo during transit.
Support for Securing Mechanisms: Moreover, the beam supports various locking devices and fastening systems, thereby keeping asphalt loads and equipment firmly secured.
Altogether, this robust main beam design ensures that the asphalt tanker trailer performs reliably under demanding conditions while fully meeting stringent safety and operational standards for heavy-duty bitumen transport.
Tractor & Trailer Connection Compatibility
Our asphalt tanker trailers are engineered to provide secure and efficient connections with a wide range of tractor units. Key compatibility features include:
Standard Fifth Wheel Coupling: Each trailer comes equipped with dependable JOST 50# active-type fifth wheel couplings. These not only comply with international safety standards but also ensure a firm and reliable tractor-to-trailer connection.
Optimized Kingpin Height: Designed with a kingpin height near 1,390mm, the trailer matches most heavy-duty tractors. This precise design allows proper alignment and balanced load transfer during operation.
Robust Landing Gear: To improve operational stability, JOST 25-ton linked landing legs provide strong support during loading, unloading, and when stationary. Consequently, this feature enhances safety on-site.
Integrated Electrical and Air Connections: Furthermore, standardized connectors for lighting and pneumatic brakes guarantee seamless integration with the tractor’s systems, thereby ensuring consistent performance and safety compliance.
Customizable Fit: For added flexibility, the trailer design can be adjusted to fit specific tractor models and operational needs, effectively accommodating various industry requirements.
Thanks to this comprehensive compatibility, users enjoy safe coupling, smooth handling, and dependable performance across various asphalt transport and road construction tasks.
🏭 Factory & Customer Testimonials
Manufacturing Display
At Shandong ZW Vehicle Group, we not only combine cutting-edge technology with expert craftsmanship but also prioritize producing top-quality asphalt tanker trailers. Our 50,000m² production facility, moreover, features advanced equipment, including CNC cutting machines, robotic welding systems, and precision assembly lines, which together ensure efficient and accurate manufacturing processes.
From raw material selection to final assembly, every trailer undergoes strict quality inspections at each stage to guarantee durability, safety, and performance. Furthermore, our team of over 200 skilled professionals is committed to upholding rigorous standards while simultaneously fostering continuous innovation.
In addition, we utilize premium-grade materials such as Q345 steel and incorporate components sourced from trusted, reputable suppliers. Consequently, every asphalt tanker trailer we produce meets or even exceeds international industry standards and reliably fulfills customer expectations.
Overall, through combining advanced technology, skilled craftsmanship, high-quality materials, and stringent quality control, Shandong ZW Vehicle Group consistently delivers dependable and high-performance asphalt tanker trailers for the global market.
Customer Feedback
We sincerely appreciate the positive feedback from our valued customers. In fact, their praise frequently highlights not only the sturdy construction but also the dependable performance and versatility of our asphalt tanker trailers. Specifically, many clients commend the trailers’ durable build as well as their smooth operation. Furthermore, the low maintenance requirements contribute significantly to improved logistics efficiency and, as a result, reduced downtime.
Moreover, customers often emphasize how these advantages combine to deliver excellent return on investment and consistent operational reliability. Therefore, we remain committed to continuously enhancing our trailers to meet and exceed customer expectations.
📈 Case Studies & FAQs
Successful Delivery Cases
Shandong ZW Vehicle Group has built a strong track record delivering asphalt tanker trailers to customers worldwide. Over the years, our trailers have demonstrated exceptional reliability and durability. In fact, they consistently perform well in various demanding environments. Whether used for road construction or large-scale asphalt logistics, our products consistently exceed customer expectations due to their robust performance and versatile adaptability.
Moreover, every shipment receives careful handling to ensure full compliance with quality and safety standards. This strong commitment not only guarantees safe delivery but also highlights our ability to meet diverse asphalt transportation needs across global markets. As a result, we continue to strengthen our reputation as a trusted supplier in the industry.
❓FAQ
Q1: What materials are used?
A1: We use high-quality Q345 steel and thermal insulation for durability and heat retention.
Q2: How is asphalt safety ensured?
A2: Insulated tanks, heating systems, and reliable brakes keep asphalt safe during transport.
Q3: Are the trailers suitable for long distances?
A3: Yes, they maintain heat well and support heavy loads for long hauls.
Q4: What after-sales support do you provide?
A4: We offer spare parts, maintenance help, and fast technical support.
Q5: Can trailers be customized?
A5:Yes, options include different tank sizes, heating, and chassis types.
Q6: How is shipping handled?
A6:We arrange secure packing, global shipping, and assist with customs.
