Detailed Description
The 2 Axle 40FT Skeletal Semi Trailer is an ideal choice for transporting ISO containers with maximum flexibility. Its open skeletal frame design accommodates various container sizes, ensuring ease of loading and unloading. Constructed with a 500mm high main beam made from durable Q345 carbon steel, this trailer guarantees excellent strength and resistance to torsion.
Equipped with two 13-ton axles from trusted Chinese brands and a mechanical suspension system, it ensures smooth rides and stable handling across different terrains. The platform features a 3mm-thick diamond plate for added durability. With eight 315/80R22.5 tires from Triangle and a 50mm bolt-in kingpin, the trailer is built for safe and reliable operation.
Additional features include a 25-ton JOST landing gear, a 1500mm high movable headboard, 14 side stick pipes for secure cargo support, and 12 container twist locks to firmly fasten containers during transit. A standard tool box is also included for operational convenience.
ZW Group provides comprehensive export support, including factory inspection and worldwide shipment logistics, backed by over 10 years of manufacturing expertise. This skeletal trailer is perfectly suited for intermodal container transport, port logistics, and heavy freight operations worldwide.
Product Video
Key Features
Versatile Container Transport: Supports 20ft and 40ft containers with 12 twist locks for secure fastening.
Robust Frame: Built with high-strength Q345 carbon steel main beam, offering excellent durability and load resistance.
Reliable Suspension: Equipped with mechanical suspension for stable and smooth cargo handling.
Trusted Axles: 2 axles rated at 13 tons each from reputable Chinese brands, ensuring dependable performance.
Durable Tires: Fitted with 8 units of 315/80R22.5 tires from Triangle brand for enhanced traction and stability.
Heavy-Duty Landing Gear: 25-ton JOST landing gear providing stable support during loading and parking.
Practical Design: Features 1500mm high movable headboard and side stick pipes for flexible cargo securing.
Additional Storage: Includes a standard tool box for convenient on-the-road maintenance and equipment storage.
Structure Diagram of Skeleton Trailer
This section features a detailed CAD drawing and an exploded view of the skeleton trailer, showcasing the chassis structure, kingpin position, axle configuration, and key mounting points. It provides a clear visual reference for engineering layout and component integration.
Specifications
| Specification | Details |
|---|---|
| Overall Dimension (L×W×H) | 12500 × 2500 × 1550 mm |
| Loading Weight | 40,000 kg |
| Main Beam | Height 500mm; Upper Plate 14mm; Middle Plate 8mm; Lower Plate 16mm; Q345 Carbon Steel |
| Axle Brand | 13 Ton, Chinese Brand |
| Number of Axles | 2 |
| Suspension System | Mechanical Suspension |
| Platform Plate Thickness | 3 mm Diamond Plate |
| Tire Type and Quantity | 315/80R22.5, 8 units, Triangle Brand |
| King Pin | 50 mm, Bolt-in Type |
| Landing Gear | 25 Ton, JOST Brand |
| Head Board | 1500 mm High, Movable |
| Side Stick Pipe | 14 Pieces Total (7 per side), Movable |
| Container Twist Locks | 12 Sets |
| Tool Box | 1 Standard |
Application Scenarios
The ZW Group 2 Axle 40FT Skeletal Semi Trailer is widely used in various logistics and transport environments due to its versatile design and strong load capacity. Typical application scenarios include:
Container Transport: Efficiently handles 20ft and 40ft containers, ideal for port terminals and intermodal freight transfer.
Inland Logistics: Perfect for moving containers between warehouses, distribution centers, and rail yards.
Construction Sites: Suitable for transporting heavy equipment and building materials in rugged environments.
Cross-border Freight: Reliable for long-distance haulage across international borders, ensuring secure cargo handling.
Shipping and Export: Designed for easy loading and unloading at shipping docks and export terminals.
This trailer offers durability and flexibility, meeting the demanding needs of modern logistics and freight industries.
ZW Group Manufacturing Base
ZW Group operates a modern manufacturing facility covering 50,000m², equipped with advanced production lines and a skilled workforce of over 200 professionals. From steel cutting to final assembly, every trailer and truck body is crafted with precision to ensure quality, consistency, and durability across all product series.
Shipping Scenarios
ZW Group ensures safe and efficient shipment of all types of semi trailers through expert loading, streamlined customs clearance, and organized port operations. Each unit undergoes thorough preparation to guarantee smooth global delivery, providing reliable logistics support for diverse transportation needs.
❓FAQ
Q1: What types of containers can this skeletal semi trailer carry?
A: It supports standard 20ft and 40ft containers with 12 twist locks for secure fastening.
Q2: What is the maximum loading capacity?
A: The trailer can safely carry up to 40,000 kg (40 tons).
Q3: What suspension system does it use?
A: It is equipped with a reliable mechanical suspension system for stable transportation.
Q4: Which tire brands are used on this trailer?
A: The trailer uses 315/80R22.5 tires, commonly with Triangle brand for durability.
Q5:Is customization available?
A: Yes, ZW Group offers OEM/ODM customization for axle brands, paint colors, and other options.
